MA075
Hand Chain Hoist - MA Series
7 1/2 Metric ton capacity
- Increased efficiency by additional pinion shaft bearing and close tolerances
- Hook blocks are bolted, allowing complete hook inspection
- Lightweight and durable all steel construction with powder coated finish and plated frame components to resist corrosion
- Premium USA-Made Precision hoist load chain with strength of G80 chain
- Hand chain opening is formed with a radius for smooth operation
- Weston style mechanical load brake is self-adjusting with double pawls, asbestos-free brake discs and is surrounded by an enclosure to limit contamination.
- Sealed ball bearings on the chain wheel maximize efficiency and serviceability
- Self-adjusting double pawl disc type mechanical load brake insures positive load control
- Double roller guide insures load chain tracking
- Optional Overload Protection is a one directional clutch that will only slip in the lift direction
- Meets: ASME/ANSl B30.16, OSHA, NASA-STD-8719.9
- ATEX rated
certified II 3 GD c IIB 54º C X for limited use in Hazardous Environments
Data Sheet MA075
| Capacity (WLL) | Capacity (WLL) | Parts | Chain | A” | B” | C” | D” | E” | P(lbs) @WLL | W(lbs) / ft. lift | W(lbs) 10ft. lift |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7.5t | 16500 lbs | 3 | C9X27Z | 29.8 | 7.4 | 1.93 | 1.81 | 16.9 | 79 | 4.13 | 135 |
Parts:
3
Capacity (WLL):
7.5t
Capacity (WLL):
16500 lbs
Chain:
C9X27Z
A”:
29.8
B”:
7.4
C”:
1.93
D”:
1.81
E”:
16.9
P(lbs) @WLL:
79
W(lbs) / ft. lift:
4.13
W(lbs) 10ft. lift:
135
